Cords
Plus has been
supplying
telephone and
communication products, supplies and services
since
1992. Cords, Cables and
Adapters for Electronic Products and Equipment of 3.5mm, Cat5
e,
DVI,
Fire Wire, HDMI, Optical,
PC Internal, Power, PS/2, RCA Coax Digital, RCA Component,
RCA
Composite, Sata,
S-Video, VGA, USB, Adapters, Gender Changers,
Cellular Antennas,
Cellular
Amplifiers, Cellular Wireless Hub Antenna Kits, Antenna Cables and
Adapters
Batteries,
Cellular Home / Travel Chargers, Vehicle Chargers, Cases,
PDA Stylus, Vehicle
Mounts,Computer
Keyboards, Mouse’s, Pads, Adapters,
Telephone Single Line
Sets,
Two
Line Phones, Handset Y Adapters, Telephone Attachments and
Accessories, Line and
Handset
Cords, Connectors, Splitters, Demarcation
Terminals, AC Power Adapter Extension Cords, Keystone
Plates,
Inserts, LED, LED Flash Lights, Wi-Fi Antennas
|
Best Viewed 1024 x 768 Screen
Resolution
|
|
Cable
Talk
AC
Adapter Power Extension Cords
Add
up to another 48 feet to your AC adapter power cord from the smaller
diameter
jack instead of adding a standard extension cord to the AC
adapter. Extending
your power using the smaller diameter cord is easier to handle, route
around stuff and hide.
We make our extension cords using 24 AWG zip wire with 3.5
amp capacity
using six
different jack and plugs to fit most AC adapters using a barrel style
connector.
USB
Cables
Used
to
connect all of your USB devices, A/B cables are designed to
connect from the USB port on a hub, PC or Mac to your USB device.
These fully-rated universal serial bus cables are backward compatible
with USB 1.1 and 1.0 devices and provide transfer rates up to 480
Mbps depending on USB version. The maximum length of a
standard USB cable for USB 2.0 or earlier is 5.0 meters
(16.4 ft).
The primary reason for this limit is the maximum allowed round-trip
delay of about 1,500 ns. If USB host commands are unanswered by
the USB device within the allowed time, the host considers the
command lost. When adding USB device response time, delays
from the maximum number of hubs add to the delays from
connecting cables, the maximum acceptable delay per
cable amounts to be 26 ns.
2.5mm
or 3.5mm Audio Cables
Audio
connectors are used to affix cables to other audio equipment,
providing electronic signal transference and grounding protection.
Connectors may be plugs, jacks, or combinations, plug type audio
connectors are male connector includes
a pin that can be
inserted into a socket. Jack type audio connectors
are female
consists of socket that are aligned to
mesh with a pin-type
connector.
DVI
Cables
DVI
( Digital Video Interface
) is a video
cable
connector designed
at maximizing the picture quality of digital display devices
such as
digital projectors and LCD screens.
DVI connectors
are
classified
into DVI-D ( DVI Digital ), DVI-A ( DVI Analog ), and DVI-I ( Digital
and Analog). If there is a provision for a second link, that
connector is referred to as DVI-DL (Dual Link).
HDMI Cables
HDMI
( High-Definition Multimedia Interface ) is an interface
standard used for audiovisual equipment such as high-definition
television and hone theater systems. With 19 wires wrapped
in a single cable that resembles a USB wire, HDMI
is able to
carry a bandwidth of 5 Gbps ( gigabits per second ). This
is more than twice the bandwidth needed to transmit
multi-channel audio and video. HDMI supports standard video
formats, enhanced video and high-definition. It is also backwards
compatible with DVI ( Digital Video Interface ). High-end
graphics
cards featuring a DVI port can connect to a HDMI
interface via
a DVI / HDMI cable. This is simply a cable with a DVI
connector on one end and a HDMI
connector on the other.
Firewire
IEEE 1394 Cables
FireWire
is Apple
Computer's version of a standard, IEEE
1394,
High
Performance Serial Bus, for connecting devices to your
personal computer.
FireWire provides a single plug-and-socket
connection
on which up to 63 devices can be attached with data
transfer
speeds up to 400 Mbps
( megabits
per second ).
Digital
Video
camcorders, scanners, printers,
videoconferencing
cameras,
and fixed-disk drives can all share a common bus
connection
not only to a PC, but to each other as well. as
connecting
two computers together to allow for file
sharing.
Use the 6-pin
cable to provide power to devices, and the
4-pin for
non-powered devices
|
|
